Aviation Aluminum body.
Ultra white tempered glass.
Silicone gasket.
High efficiency PMMA lens.
Anti-corrosion electrostatic powder coating.
Stainless steel external screws and mounting plate.
Special surface treatment is required for special coastal environments.
Structurally waterproof, detachable for easy replacement of LED, lens, and driver.
| Model | Power | Beam angle | CCT | Luminous flux | Control | SDCM | CRI | LED | Voltage | Weight |
|---|---|---|---|---|---|---|---|---|---|---|
| ET6022 | 44W | 15° / 24° / 36° / 50° / 20°x50° | 2700K / 3000K / 4000K / 5000K | 3664lm(3000K 15°) | ON/OFF | 3 | 80 | COB*1 | 100V-240V | 7.2KG |
Electrical and Control
| Voltage | 100V-240V |
| Power | 44W |
| Power Supply | Built-in |
| Control | ON/OFF / 0-10V / DALI |
| Cable | 0.5M H05RN-F 3x1mm2 |
| Environmental | -20 °C ~ 50 °C |
LED and Optics
| LED Brand | CITIZEN / CREE |
| LED Quantity | COB X 1 |
| Beam Angle | 15° / 24° / 36° / 50° / 20°x50° |
| Delivered Lumen | (3000K 15°)3664lm |
| Colour Rendering | CRI 80 |
| SDCM | 3 |
| CCT | 2700K / 3000K / 4000K / 5000K |
| LED Optic | PMMA Lens |
Physical
| Housing | Die-cast aluminum |
| Lens Material | Tempered glass |
| External Screw | Stainless steel material |
| Surface Treatment | Anticorrosive coating |
| Net Weight | 7.2KG |
| Warranty | 3 years |
| Rating | IP65 |
| Impact Protection | IK08 |
| Certifications | CE |
