Die cast aluminum casing.
Ultra white tempered glass.
Silicone gasket.
High efficiency PMMA lens.
Anti-corrosive electrostatic powder coating
Stainless steel external screws and mounting plate.
Special surface treatment is required for special coastal environments.
Structurally waterproof, detachable for easy replacement of LED, lens, and driver
| Model | Power | Beam angle | CCT | Luminous flux | Control | SDCM | CRI | LED | Voltage | Weight |
|---|---|---|---|---|---|---|---|---|---|---|
| ET6356 | 6W | 2° / 2° | 2700K / 3000K / 4000K / 5000K | 68lm | ON / OFF | 5 | 80 | LEDx2 | 220V-240V | 1.2Kg |
Electrical and Control
| Voltage | 220V-240V |
| Power | 6W |
| Power Supply | Built-in |
| Control | ON/OFF / 0-10V / DALI |
| Cable | 0.5M H05RN-F 3x1mm2 |
| Environmental | -20 °C ~ 50 °C |
LED and Optics
| LED Brand | CREE |
| LED Quantity | LEDx2 |
| Beam Angle | 2° / 2° |
| Delivered Lumen | 68lm |
| Colour Rendering | CRI 80 |
| SDCM | 5 |
| CCT | 2700K / 3000K / 4000K / 5000K |
| LED Optic | PMMA Lens |
Physical
| Housing | Die-cast aluminum |
| Lens Material | Tempered glass |
| External Screw | Stainless steel material |
| Surface Treatment | Anticorrosive coating |
| Net Weight | 1.2KG |
| Warranty | 3 years |
| Rating | IP65 |
| Impact Protection | IK08 |
| Certifications | CE |
