A type of entirely stainless steel floodlight,which can be either used for dry or wet harsh outdoor environments.
Exquisite brushed housing surface. Fin design ensures better heat dissipation. Stainless steel 316L housing High transmittance, tempered glass without light shifting ensures consistency of CCT of LEDs.
Stainless steel exposed screws and mounting bracket.
Suitable for waterscape and some harsh environmental landscape lighting.
| Model | Power | Beam angle | CCT | Luminous flux | Control | SDCM | CRI | LED | Voltage | Weight |
|---|---|---|---|---|---|---|---|---|---|---|
| ET7123 | 4W | 8° / 15° / 30° / 45° / 60° / 15°*45° | 2700K / 3000K / 4000K / 5000K | 330lm(3000K 15°) | ON / OFF | 5 | 80 | LEDx1 | 24VDC | 0.4KG |
Electrical and Control
| Voltage | 24VDC |
| Power | 4W |
| Power Supply | Built-in |
| Control | ON/OFF / 0-10V / DALI |
| Cable | 0.5M H05RN-F 3x1mm2 |
| Environmental | -20 °C ~ 50 °C |
LED and Optics
| LED Brand | CITIZEN / CREE |
| LED Quantity | COB X 1 |
| Beam Angle | 15° / 24° / 36° / 50° / 20°x50° |
| Delivered Lumen | 330lm (3000K 15°) |
| Colour Rendering | CRI 80 |
| SDCM | 5 |
| CCT | 2700K / 3000K / 4000K / 5000K |
| LED Optic | PMMA Lens |
Physical
| Housing | Die-cast aluminum |
| Lens Material | Tempered glass |
| External Screw | Stainless steel material |
| Surface Treatment | Anticorrosive coating |
| Net Weight | 0.4KG |
| Warranty | 3 years |
| Rating | IP68 |
| Impact Protection | IK09 |
| Certifications | CE |
