ET7123

  • Product Introduction

A type of entirely stainless steel floodlight,which can be either used for dry or wet harsh outdoor environments.

Exquisite brushed housing surface. Fin design ensures better heat dissipation. Stainless steel 316L housing High transmittance, tempered glass without light shifting ensures consistency of CCT of LEDs.

Stainless steel exposed screws and mounting bracket.

Suitable for waterscape and some harsh environmental landscape lighting.


Model Power Beam angle CCT Luminous flux Control SDCM CRI LED Voltage Weight
ET7123 4W 8° / 15° / 30° / 45° / 60° / 15°*45° 2700K / 3000K / 4000K / 5000K 330lm(3000K 15°) ON / OFF 5 80 LEDx1 24VDC 0.4KG
  • Specifications
  • Download
  • Accessory

ET7123

Electrical and Control

Voltage 24VDC
Power4W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-20 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityCOB X 1
Beam Angle15° / 24° / 36° / 50° / 20°x50°
Delivered Lumen330lm (3000K 15°)
Colour RenderingCRI 80
SDCM5
CCT2700K / 3000K / 4000K / 5000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight0.4KG
Warranty3 years
RatingIP68
Impact ProtectionIK09
CertificationsCE
