ET7701

  • Product Introduction

Wing, a high-power, multi application, multi combination and multi specification circular floodlight. Self-circulating air convection structure maximally improve the heat dissipation

efficiency of the lamp. Internal anti glare hood to reduce glare.

The lamp with no exposed cable can adjust the projection direction vertically and horizontally.

Die cast aluminum casing.

Ultra white tempered glass.

Silicone gasket.

High efficiency PMMA lens.

Anti-corrosion electrostatic powder coating.

Stainless steel external screws and mounting plate.

Detachable structural waterproof process ensures sustainable usage and reduces maintenance costs.

Suitable for building facade precise lighting and poles multi-directional lighting in public places.


Model Power Beam angle CCT Luminous flux Control SDCM CRI LED Voltage Weight
ET7701.RGBW 26W 7° / 15° / 25° / 45° / 60° / 15°*40° 2700K / 3000K / 4000K / 5000K 921lm（3000K 15°） DMX512 80 LEDx4 24VDC 1.6KG
ET7701 26W 5° / 15° / 24° / 36° / 50° /20°*50° 2700K / 3000K / 4000K / 5000K 2105lm(3000K 15°) ON / OFF 3 80 COBx1 100V-240V 1.6KG
  • Specifications
  • Download
  • Accessory

ET7701.RGBW

Electrical and Control

Voltage 100V-240V
Power26W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-20 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityLED X 4
Beam Angle7° / 15° / 25° / 45° / 60° / 15°*40°
Delivered Lumen921lm（3000K 15°）
Colour RenderingCRI 80
SDCM
CCT2700K / 3000K / 4000K / 5000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight1.6KG
Warranty3 years
RatingIP66
Impact ProtectionIK08

Electrical and Control

Voltage 220V-240V
Power42W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-20 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityCOB X 1
Beam Angle15° / 24° / 36° / 50° / 20°x50°
Delivered Lumen3608lm (3000K 24°)
Colour RenderingCRI 80
SDCM3
CCT2700K / 3000K / 4000K / 5000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight3.5KG
Warranty3 years
RatingIP65
Impact ProtectionIK08
CertificationsCE



ET7701.RGBW

Documents

ET7701.RGBW

Optional accessories

  • Specifications
  • Download
  • Accessory

ET7701

Electrical and Control

Voltage 100V-240V
Power26W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-20 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityCOB X 1
Beam Angle5° / 15° / 24° / 36° / 50° / 20°*50°
Delivered Lumen2105lm（3000K 15°）
Colour RenderingCRI 80
SDCM
CCT2700K / 3000K / 4000K / 5000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight1.6KG
Warranty3 years
RatingIP66
Impact ProtectionIK08

Electrical and Control

Voltage 220V-240V
Power42W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-20 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityCOB X 1
Beam Angle15° / 24° / 36° / 50° / 20°x50°
Delivered Lumen3608lm (3000K 24°)
Colour RenderingCRI 80
SDCM3
CCT2700K / 3000K / 4000K / 5000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight3.5KG
Warranty3 years
RatingIP65
Impact ProtectionIK08
CertificationsCE



ET7701

Documents

ET7701

Optional accessories
