ET7725

  • Product Introduction

Wing, a high-power, multi application, multi combination and multi specification circular floodlight. Self-circulating air convection structure maximally improve the heat dissipation

efficiency of the lamp. Internal anti glare hood to reduce glare.

The lamp with no exposed cable can adjust the projection direction vertically and horizontally.

Die cast aluminum casing.

Ultra white tempered glass.

Silicone gasket.

High efficiency PMMA lens.

Anti-corrosion electrostatic powder coating.

Stainless steel external screws and mounting plate.

Detachable structural waterproof process ensures sustainable usage and reduces maintenance costs.

Suitable for building facade precise lighting and poles multi-directional lighting in public places.


Model Power Beam angle CCT Luminous flux Control SDCM CRI LED Voltage Weight
ET7725.RGBW 42W 7° / 15° / 25° / 45° / 60° / 15°*30° 2700K / 3000K / 4000K / 5000K DMX512 80 LEDx6 24VDC 2.5KG
ET7725 42W 5° / 15° / 24° / 36° / 50° / 20°*50° 2700K / 3000K / 4000K / 5000K 3290lm(3000K 15°) ON / OFF 3 80 COBx4 100V-240V 2.5KG
  • Specifications
  • Download
  • Accessory

ET7725.RGBW

Electrical and Control

Voltage24VDC
Power42W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-40 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityLED X 6
Beam Angle5° / 15° / 24° / 36° / 50° / 20°*50°
Delivered Lumen
Colour RenderingCRI 80
SDCM3
CCT2700K / 3000K / 4000K / 5000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight2.5KG
Warranty3 years
RatingIP66
Impact ProtectionIK08
CertificationsCE


ET7725.RGBW

Documents

ET7725.RGBW

Optional accessories

  • Specifications
  • Download
  • Accessory

ET7725

Electrical and Control

Voltage 100V-240V
Power42W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-40 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityCOB X 4
Beam Angle5° / 15° / 24° / 36° / 50° / 20°*50°
Delivered Lumen3290lm(3000K 15°)
Colour RenderingCRI 80
SDCM3
CCT2700K / 3000K / 4000K / 5000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight2.5KG
Warranty3 years
RatingIP66
Impact ProtectionIK08
CertificationsCE


ET7725

Documents

ET7725

Optional accessories
