ET7084

  • Product Introduction

Wing, a high-power, multi application, multi combination and multi specification circular floodlight. Self-circulating air convection structure maximally improve the heat dissipation

efficiency of the lamp. Internal anti glare hood to reduce glare.

The lamp with no exposed cable can adjust the projection direction vertically and horizontally.

Die cast aluminum casing.

Ultra white tempered glass.

Silicone gasket.

High efficiency PMMA lens.

Anti-corrosion electrostatic powder coating.

Stainless steel external screws and mounting plate.

Detachable structural waterproof process ensures sustainable usage and reduces maintenance costs.

Suitable for building facade precise lighting and poles multi-directional lighting in public places.


Model Power Beam angle CCT Luminous flux Control SDCM CRI LED Voltage Weight
ET7084.RGBW 120W 7°/15°/25°/45°/60°/15°*30° 2700K/3000K/4000K/5000K 2661lm(3000K 15°) DMX512 80 LEDx18 100V-240V 7.4KG
ET7084 120W 5° / 15° / 36° / 50° / 20*50° 2700K / 3000K / 4000K / 5000K 9676lm(3000K 15°) ON / OFF 3 80 COBx6 100V-240V 7.4KG
  • Specifications
  • Download
  • Accessory

ET7084.RGBW

Electrical and Control

Voltage100V-240V
Power120W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-40 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityLED X 18
Beam Angle7°/15°/25°/45°/60°/15°*30°
Delivered Lumen
Colour RenderingCRI 80
SDCM
CCT2700K / 3000K / 4000K / 5000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight7.4KG
Warranty3 years
RatingIP66
Impact ProtectionIK08
CertificationsCE


ET7084.RGBW

Documents

ET7084.RGBW

Optional accessories

  • Specifications
  • Download
  • Accessory

ET7084

Electrical and Control

Voltage100V-240V
Power120W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-40 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityCOB X 4
Beam Angle5° / 15° / 36° / 50° / 20*50°
Delivered Lumen
Colour RenderingCRI 80
SDCM
CCT2700K / 3000K / 4000K / 5000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight7.4KG
Warranty3 years
RatingIP66
Impact ProtectionIK08
CertificationsCE


ET7084

Documents

ET7084.IES

ET7084

Optional accessories

  • Information
  • Downloads
  • Accessories
  • Service

71 025

DALI cross switch

DALI cross switch
sdsdsds

71 025

DALI cross switch

DALI cross switch
Documents

Product data sheet

Product data sheet

The technical specifications in the instructions for use, product data sheets and quotation texts refer to the products manufactured at the time of publication. We are constantly working to improve the performance and efficiency of our products. The goods delivered may therefore deviate slightly from those advertised.
