ET2005

  • Product Introduction

The professional structure and optical lighting design provide a comfortable lighting environment while meeting the lighting needs.

 Die cast aluminum casing.

Ultra white tempered glass.

Silicone gasket.

High efficiency PMMA lens.

Anti-corrosion electrostatic powder coating.

Stainless steel external screws and mounting plate.

Detachable structural waterproof process ensures sustainable usage and reduces maintenance costs.

Suitable for villas, park trails, garage entrances and exits, etc. platform, etc.



Model Power Beam angle CCT Luminous flux Control SDCM CRI LED Voltage Weight
ET2005 12W 360° 2700K / 3000K / 4000K 365lm ON/OFF 5 80 SMDx24 180V-264V 1.5Kg
  • Specifications
  • Download
  • Accessory

ET2005

Electrical and Control

Voltage180V-264V
Power12W
Power SupplyRemote
ControlON/OFF / 0-10V / DALI
Cable0.3M H05RN-F 3x1mm2
Environmental                                                                                        -30 °C ~ 50 °C


LED and Optics

LED BrandOSRAM
LED QuantitySMDx24
Beam Angle360°
Delivered Lumen365lm
Colour RenderingCRI 80
SDCM5
CCT2700K / 3000K / 4000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight1.5KG
Warranty3 years
RatingIP65
Impact ProtectionIK08
CertificationsCE



ET2005

Documents

ET2005

ET2005
