Recessed Underwater luminaires——Asymmetric optics
Using a specially designed multiple reflection principle,
the light is efficiently emitted in an asymmetric direction to achieve uniform wall cleaning and anti glare effects.
The product is suitable for installation in key lighting applications such as corridors, walls, and sculptures.
Stainless steel body.
Stainless steel decorative bezel.
Ultra white tempered glass.
Silicone gasket.
High efficiency PMMA lens.
Stainless steel external screws.
Strengthened PP mounting sleeve.
| Model | Power | Beam angle | CCT | Luminous flux | Control | SDCM | CRI | LED | Voltage | Weight |
|---|---|---|---|---|---|---|---|---|---|---|
| ET9341 | 10W | 360° | 2700K / 3000K / 4000K / 5000K | 490lm | ON/OFF | 3 | 80 | COBx1 | 12VDC | 2.8Kg |
Electrical and Control
| Voltage | 12VDC |
| Power | 10W |
| Power Supply | Remote |
| Control | ON/OFF / 0-10V / DALI |
| Cable | 0.5M H05RN-F 3x1mm2 |
| Environmental | -40 °C ~ 50 °C |
LED and Optics
| LED Brand | CREE / CITIZEN |
| LED Quantity | COBx1 |
| Beam Angle | 360° |
| Delivered Lumen | 490lm |
| Colour Rendering | CRI 80 |
| SDCM | 3 |
| CCT | 2700K / 3000K / 4000K / 5000K |
| LED Optic | PMMA Lens |
Physical
| Housing | Stainless steel material |
| Lens Material | Tempered glass |
| External Screw | Stainless steel material |
| Surface Treatment | Anticorrosive coating |
| Net Weight | 2.8KG |
| Warranty | 3 years |
| Rating | IP68 |
| Impact Protection | IK09 |
| Certifications | CE |
