LED Bollard—— Footpath
Aviation aluminum profile .
Ultra white tempered glass.
Silicone gasket.
Anti-corrosion electrostatic powder coating.
Stainless steel external screws and mounting plate.
On/off standard, DALI , 0-10V or Traic dimming is optional.
| Model | Power | Beam angle | CCT | Luminous flux | Control | SDCM | CRI | LED | Voltage | Weight |
|---|---|---|---|---|---|---|---|---|---|---|
| ET5170.H | 15W | 360° | 2700K / 3000K / 4000K | 905lm | ON/OFF | 5 | 80 | COBx1 | 220V-240V | 3.9Kg |
Electrical and Control
| Voltage | 220V-240V |
| Power | 15W |
| Power Supply | Built-in |
| Control | ON/OFF / 0-10V / DALI |
| Cable | 0.3M H05RN-F 3x1mm2 |
| Environmental | -20 °C ~ 50 °C |
LED and Optics
| LED Brand | CREE / CITIZEN |
| LED Quantity | COBx1 |
| Beam Angle | 360° |
| Delivered Lumen | 905lm |
| Colour Rendering | CRI 80 |
| SDCM | 5 |
| CCT | 2700K / 3000K / 4000K |
| LED Optic | PMMA Lens |
Physical
| Housing | Die-cast aluminum |
| Lens Material | Tempered glass |
| External Screw | Stainless steel material |
| Surface Treatment | Anticorrosive coating |
| Net Weight | 3.9KG |
| Warranty | 3 years |
| Rating | IP65 |
| Impact Protection | IK08 |
| Certifications | CE |
