ET5167

  • Product Introduction

Aviation aluminum profile .

Ultra white tempered glass.

Silicone gasket.

Anti-corrosion electrostatic powder coating.

Stainless steel external screws and mounting plate.

On/off standard, DALI , 0-10V or Traic dimming is optional.

No upward lighting, and the lighting distribution evenly throws on the ground.

Adopting a directional multi particle asymmetric reflecting device, resulting inhigher luminous efficiency and wider directional irradiation range.

Modular system, head and pole can be quickly interchanged.

The anchoring devices provided by ET Lighting are all made of SS304 material,

with high strength, corrosion resistance, and long lifetime.


Model Power Beam angle CCT Luminous flux Control SDCM CRI LED Voltage Weight
ET5167 12W 360° 2700K / 3000K / 4000K 498lm ON/OFF 5 80 SMDx35 180V-264V 5.2Kg
  • Specifications
  • Download
  • Accessory

ET5167

Electrical and Control

Voltage180V-264V
Power12W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental                                                                                        -30 °C ~ 50 °C


LED and Optics

LED BrandOSRAM
LED QuantitySMDx35
Beam Angle360°
Delivered Lumen498lm
Colour RenderingCRI 80
SDCM5
CCT2700K / 3000K / 4000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight5.2KG
Warranty3 years
RatingIP65
Impact ProtectionIK08
CertificationsCE



ET5167

Documents

ET5167.IES

ET5167

Optional accessories

  • Information
  • Downloads
  • Accessories
  • Service

71 025

DALI cross switch

DALI cross switch
sdsdsds

71 025

DALI cross switch

DALI cross switch
Documents

Product data sheet

Product data sheet

The technical specifications in the instructions for use, product data sheets and quotation texts refer to the products manufactured at the time of publication. We are constantly working to improve the performance and efficiency of our products. The goods delivered may therefore deviate slightly from those advertised.
