ET5024

  • Product Introduction

Bollard is a special product that must be exposed to the landscape environment.

With simple design and texture, bollards can integrate with architecture and provide high-quality optical lighting.

It is part of the architectural landscape during the day and provides lighting guidance.

Suitable for villas, park landscape, etc.

Die casting aluminum body.

Ultra white tempered glass.

Silicone gasket.

High efficiency PMMA lens.

Anti-corrosion electrostatic powder coating.

Stainless steel external screws and mounting plate.

The housing height can be customized.

Modular lamp holder, easy to disassemble, rotatable fixing method, locked with one screw, optimized for product aesthetics.

ET can provide up to 10 years of product replacement parts services, continuously optimizing products while also balancing the sustainable use of old products.

Secondary optical design of downward illumination, and Backlight optical reflection is adopted to meet the needs of different scenes. The optical distribution is designed with downward polarization, which will not cause glare and light pollution of parallel viewing angle, and can

achieve 100% efficiency of lighting.

Adopting ultra-high light efficiency reflective optics, avoiding direct light and reducing the presence of glare. Adopting precision scale reflector, it can achieve large-scale flooding and provide product efficiency.


Model Power Beam angle CCT Luminous flux Control SDCM CRI LED Voltage Weight
ET5083-500mm 26W 360° 2700K / 3000K / 4000K 1140lm ON/OFF 5 80 SMDx48 220V-240V 6.8Kg
ET5024-800mm 26W 360° 2700K / 3000K / 4000K 1140lm ON/OFF 5 80 SMDx48 220V-240V 8.2Kg
  • Specifications
  • Download
  • Accessory

ET5083-500mm

Electrical and Control

Voltage220V-240V
Power26W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental                                                                                        -20 °C ~ 50 °C


LED and Optics

LED BrandOSRAM
LED QuantitySMDx48
Beam Angle360°
Delivered Lumen1140lm
Colour RenderingCRI 80
SDCM5
CCT2700K / 3000K / 4000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight6.8KG
Warranty3 years
RatingIP65
Impact ProtectionIK08
CertificationsCE






ET5083-500mm

Documents

ET5083-500mm

Optional accessories

  • Specifications
  • Download
  • Accessory

ET5024-800mm

Electrical and Control

Voltage220V-240V
Power26W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental                                                                                        -20 °C ~ 50 °C


LED and Optics

LED BrandOSRAM
LED QuantitySMDx48
Beam Angle360°
Delivered Lumen1140lm
Colour RenderingCRI 80
SDCM5
CCT2700K / 3000K / 4000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight8.2KG
Warranty3 years
RatingIP65
Impact ProtectionIK08
CertificationsCE





ET5024-800mm

Documents

ET5024-800mm

Optional accessories
